Electric Pallet Tilter Pallet Truck (1000kg)

Effortlessly streamline material handling tasks with our LT Series Electric Pallet Tilter, designed for ergonomic precision and versatility.

Description

Electric Pallet Tilter Pallet Truck – LT Series, engineered to streamline material handling tasks with ergonomic precision and efficiency.

Standard Features:

  • Available in Manual or Electric versions for versatile usage.
  • Facilitates effortless tilting and transportation of crates/pallet mesh.
  • Designed to provide users with an ergonomic position for easy load access, minimizing the need for bending or stretching.
  • Handle can be securely turned and locked away from the work area.
  • Suitable for both sitting and standing positions, enhancing operator comfort.
  • Forks can be lifted up to 90 degrees for flexible handling.
  • Equipped with parking brake and foot protectors for added safety.
  • Capable of handling loads up to 1 tonne with ease.
  • Comes with up to 1-year warranty for peace of mind.

For detailed product specifications, feel free to contact us.

Specifications

ELECTRIC PALLET TILTER – LT SERIES spec

ModelLT10M
TypeManual
Capacity (kg)1000
Lifting Height, Vertical h (mm)285
Min. Fork Height h1 (mm)85
Fork Length l (mm)800
Handle Height L1 (mm)1138
Overall Fork Width b (mm)560
Width Between Forks b1 (mm)234
Fork Tip Length from Roller L2 (mm)135
Overall Width B (mm)638
Overall Length L (mm)1325
Overall Height, Raised H (mm)950
Overall Height, Lowered H (mm)750
Load Centre Min./Max. C1 (mm)200/400
Load Centre Min./Max. C2 (mm)200/420
Power Unit (kW/V)-
Net Weight (kg)178
