Aerial Work Platform Up to 12m

The Aerial Work Platform Scissors- RS1212 is designed for safe and efficient elevated work, featuring proportional control and emergency lowering for enhanced safety. With an explosion-proof oil pipeline and pothole protection, this robust platform ensures stability and reliability for various applications.


Description

Introducing the Aerial Work Platform Scissors- RS1212, designed for safe and efficient elevated work. This robust platform ensures maximum productivity and security with its advanced features.

Standard features:

  • Proportional control for precise movements
  • Emergency lowering system for added safety
  • Hour meter for tracking usage
  • Explosion-proof oil pipeline
  • Charging position regulation for efficient power management
  • Pothole protection for stability on uneven surfaces

Specification

ModelRS1212
MeasurementUSMetric
A1 - Working Height Maximum*45 ft 7 in13.9m
A2 - Platform Height Maximum39 ft 1 in11.9m
B - Length-Stowed8 ft 1 in2.46m
C - Width3 dt 9 in1.15m
D - Height Stowed - Fixed Rails8 ft 6 in2.6m
Height Stowed - Rails Folded6 ft 5 in1.95m
E - Platform Length - Outside7 ft 5 in2.27m
F - Side-out Platform Extension Deck3 ft 3 in1m
G - Platform Width - Outside3 ft 9 in1.15m
H - Wheelbase6 ft 1 in1.85m
I - Ground Clearance - Center4 in0.1m
J - with pothole guards deployed0.8 in0.02m
Productivity
Maximum Platform Occupancy **22
Lift Capacity705 lbs320 kg
Lift Capacity - Extension Deck265 lbs120 kg
Drive HeightFull HeightFull Height
Drive Speed - Stowed2 mph3.2 km/h
Drive Speed - Raised0.5 mph0.8 km/h
Turning Radius - Inside00
Turning Radius - Outside7 ft 7 in2.3m
Max. Work Angle of Inclination3°/1.5°3°/1.5°
ControlsProportionalProportional
DriveDual Front WheelDual Front Wheel
Multiple Disc BrakesDual Rear WheelDual Rear Wheel
Tires - Solid Non-Marking15 x 5in38 x 13cm
Power
Drive Motor1.6kW
Power Source24C DC (four 0V 220 Ah batteries)
Charger90-240V 30Amp
Hydraulic System Capacity5.8 gal22L
Weight6900 lbs3130 kg
